CM-eXT2-15W-C-DF

15.6 inch, eXT2 Xpanel, Standard HMI

15.6-inch Display
Aluminum Front/Rear Enclosure
Capacitive Multi-Touch
1920 x 1080 (16:9) Resolution
450 cd/m² Luminance
2 GB RAM
8 GB eMMC Storage
24 VDC Rated Voltage
2x Ethernet
2x Serial
1x USB Type A
1x USB-C Slot [Tool Port]
1x MicroSD Card
1x Audio Line-out
-20 – +70°C Operating Temperature
UL, CE, FCC, KC Agency Approvals
IP68 / IP69K (Front) Protection Class

Purchase Contact Us

CM-eXT2-15W-C-DF

15.6 inch, eXT2 Xpanel, Standard HMI

15.6-inch Display
Aluminum Front/Rear Enclosure
Capacitive Multi-Touch
1920 x 1080 (16:9) Resolution
450 cd/m² Luminance
2 GB RAM
8 GB eMMC Storage
24 VDC Rated Voltage
2x Ethernet
2x Serial
1x USB Type A
1x USB-C Slot [Tool Port]
1x MicroSD Card
1x Audio Line-out
-20 – +70°C Operating Temperature
UL, CE, FCC, KC Agency Approvals
IP68 / IP69K (Front) Protection Class

Purchase Contact Us

Specifications

Functional

Enclosure - Front

Aluminum

Enclosure - Rear

Aluminum

LCD Size

15.6 inch Wide TFT Color

Colors

16.7M

Resolution

1920 x 1080 WXGA (16:9)

Effective Display Area (W x H)

344.16 x 193.59 mm

PPI

Backlight

LED

Luminance

450 cd/m²

Contrast Ratio

800:1

Backlight Life

50,000 Hours

Touch Panel

10-Point Capacitive

Touch Panel Accuracy

Active Area Width (X) ±2%, Height (Y) ±2%

Display Orientation

Landscape (Standard, 180°), Portrait (90°, 270°)

Memory

2 GB LPDDR4

Storage

8 GB eMMC

SD Card

1 x MicroSD card slot

COM 1

RS-422/485

COM 2

RS-232C

Ethernet

2 x 10/100/1000 ports

USB Host

1 x Type A

Tool Port

1 x USB-C

Audio

1 x Line-out port

Rated Voltage

24 VDC, Class 2

Inrush Current

30 A maximum

Power Consumption

23.5 W (Max: 25 W)

Operating System

Embedded Linux

Project Memory

250 MB

User Memory

4 GB

Realtime Clock

Realtime clock built into panel, backed up for 10 years at 25°C

Acknowledgement Sound

Electronic buzzer

Agency Approvals - UL

UL61010-1 / UL61010-2-201 (E231117)

Agency Approvals - CE

Electromagnetic Compatibility Directive 2014/30/EU (EMC)

Agency Approvals - FCC

The 47 CFR, Part2, Part15 and Part 18 Of FCC Requirement

Agency Approvals - KC

Registration of Broadcasting and Communication Equipments

Agency Approvals - Protection Class (Front)

IP68 / IP69K, NEMA Type 4X, 12

Environmental

Operating Temperature

-20 – +70°C (-4 – +158°F)

Storage Temperature

-25 – +75°C (-13 – +167°F)

Operating Humidity

10–90% RH (below 29°C, not condensed)

Storage Humidity

10–90% RH (below 39°C, not condensed)

Altitude (Air Pressure)

700–1114 hPa (3000 m / 9800 ft or less)

Dust Exposure Allowance

≤ 0.1 mg/m³

Pollution Degree

≤ 2

Corrosion Immunity

No corrosive gas and dust

Vibration Protection

JIS B 3502, IEC/EN 61131-2 compliant
5–9 Hz Single amplitude: 3.5 mm
9–150 Hz Fixed acceleration: 9.8 m/s²
X, Y, Z directions for 10 cycles (approx. 100 min)

Shock Protection

JIS B 3502, IEC/EN 61131-2 compliant
147m/s², X, Y, Z directions for ±3 times (Total 18 times)

Noise Protection

Impulse, EFT/Burst, Surge, ±0.5 KV

Electrostatic Discharge

Contact Discharge 4 kV (IEC 61000-4-2)
Air Discharge 8 kV (IEC 61000-4-2)

Physical

Dimensions

393.6 x 247.9 x 53.9 mm (15.49 x 9.76 x 2.12 in)

Panel Cut

385 x 239 mm (15.16 x 9.41 in)

Weight

3.4 kg (7.49 lbs)

VESA (W x H)

75 mm x 75 mm
