CM-iNP-71112W-C-D

12.1 Inch 11th Gen Intel Core i7 Fanless Capacitive Industrial Panel PC

12.1-inch Display
11th Gen Intel® Core™ i7-1185G7E processor, Quad Core, 1.8 GHz (FANLESS)
Capacitive Multi-Touch
1280 x 800 Resolution
600 cd/m² Luminance
8 GB RAM
500 GB SSD
24 VDC Rated Voltage
2x Ethernet
2x Serial
4x USB 3.0
2x HDMI
-20 – +60°C Operating Temperature
UL, CE, FCC, KC Agency Approvals
IP68/IP69K (Front) Protection Class

Purchase Contact Us

CM-iNP-71112W-C-D

12.1 Inch 11th Gen Intel Core i7 Fanless Capacitive Industrial Panel PC

12.1-inch Display
11th Gen Intel® Core™ i7-1185G7E processor, Quad Core, 1.8 GHz (FANLESS)
Capacitive Multi-Touch
1280 x 800 Resolution
600 cd/m² Luminance
8 GB RAM
500 GB SSD
24 VDC Rated Voltage
2x Ethernet
2x Serial
4x USB 3.0
2x HDMI
-20 – +60°C Operating Temperature
UL, CE, FCC, KC Agency Approvals
IP68/IP69K (Front) Protection Class

Purchase Contact Us

Specifications

Functional

Enclosure - Front

Aluminum

Enclosure - Rear

Aluminum

Display

12.1 inch

CPU

11th Gen Intel® Core™ i7-1185G7E processor, Quad Core, 1.8 GHz (FANLESS)

Memory

8GB DDR4 SDRAM (Max. 32 GB)

Storage

SSD 500GB (M.2 / NVMe)

Extra Storage Option

SSD 250 GB (2.5” / SATA)

Operating System

Windows 11 IoT Enterprise (Standard) / Windows 11 Pro

Graphics

Intel® Iris® Xe Graphics

Resolution

1280x800 WXGA (16:10)

Backlight

LED

Luminance

600 cd/m²

UV Protective Coating

SPF 90

Backlight Life

50,000 hours

Touch

Capacitive

Display Ports

2 x HDMI port

COM 1

1 x RS232/422/485 port (default: RS232)

COM 2

1 x RS-232 port

Ethernet

2 x Gigabit Ethernet ports

USB

4 x USB 3.0 ports

Power Supply

DC 24V

Power Consumption

69W (MAX : 75W)

Utility Program

UWF, Winclon (Recovery System)

Agency Approvals - UL

UL61010-1 / UL61010-2-201 (E231117)

Agency Approvals - CE

Electromagnetic Compatibility Directive 2014/30/EU (EMC)

Agency Approvals - FCC

The 47 CFR, Part2, Part15 and Part 18 Of FCC Requirement

Agency Approvals - KC

Registration of Broadcasting and Communication Equipment

Agency Approvals - Protection Class

IP68 / IP69K (front)

Environmental

Operating Temperature

-20°C – +60°C (-4 – +140 °F)

Storage Temperature

-20°C – +80°C (-4 – +176 °F)

Operating Humidity

10%–90% RH (Below 29°C, No dew condensation)

Storage Humidity

10%–90% RH (Below 39°C, No dew condensation)

Environment Condition

800 hPa–1114 hPa (2000 m or less)

Dust

≤ 0.1 mg/m³

Pollution Degree

≤ Pollution Degree 2

Operating Ambience

Free from corrosive gas and excessive dust

Overvoltage Category

Category II

Vibration Resistance

9.8 m/s², 10 Hz–25 Hz in X, Y, Z (80 min)

Noise Resistance

Impulse, EFT/Burst, Surge, ±2 kV, 1 us

Static Discharge Resistance

±4 kV (contact discharge)
±8 kV (air discharge) (IEC 61000-4-2)

Physical

Dimensions

314.3 x 220.5 x 68.6 mm (12.37 x 8.68 x 2.70 in)

Panel Cut

305 x 212 mm (12.37 x 8.35 in)

Weight

2.8 kg (6.17 lb)
